2000kg Pipe Welding Positioners For Medium And Small Sized Tasks And Workpieces

Brand Name : Weldsuccess

Model Number : HBJ-20

Certification : ISO/CE/CO

Place of Origin : China

MOQ : 1 set

Price : Negotiation

Payment Terms : L/C, D/P, T/T

Supply Ability : 5 Sets Per Month

Delivery Time : 10 working days after received your payment

Packaging Details : Wooden Case

Max Capacity : 2000kg

Table Diameter : 1200mm

Type : Automatic Positioner

Product Name : Pipe Welding Positioners

Warranty : 1 Year

Clamps Way : Welding Chuck / Design

Certificate : CE Approval

Dimensions : Customizable

Contact Now

2-ton welding positioner is a piece of equipment used in welding and fabrication processes to facilitate convenient and precise welding operations. Here are some key features of a 2-ton welding positioner:

1, Load Capacity: The welding positioner is designed to handle workpieces with a maximum weight capacity of 2 tons. It is suitable for medium-sized welding tasks and workpieces.

2, Positioning Function: The equipment has a rotating function that allows the workpiece to rotate 360 degrees in the horizontal direction. This enables welders to easily adjust the position of the workpiece and find the optimal welding angle.

3, Control Operation: The welding positioner is equipped with a control panel for controlling the rotation speed and direction. Welders can achieve precise workpiece positioning by operating the buttons and knobs on the control panel.

4, Stability and Durability: The welding positioner is designed with a sturdy structure and durable materials to ensure stability and long-term use during welding operations.

5, Safety: To ensure the safety of the operators, welding positioners are typically equipped with safety devices such as emergency stop buttons and protective covers. These devices help to quickly stop the equipment in case of emergencies and provide necessary protection.

2000kg Pipe Welding Positioners For Medium And Small Sized Tasks And Workpieces2000kg Pipe Welding Positioners For Medium And Small Sized Tasks And Workpieces

Technical Parameters:

Model

HBJ-20

Loading Capacity

2000kg maximum

Table diameter

 1200mm
Rotation motor 0.75Kw
Rotation speed 0.05-0.5rpm

Tilting motor

1.5kw

Tilting speed

0.67rpm

Tilting angle

0~90°
Max.Eccentric distance 150mm

Max.Gravity distance

100mm

Voltage

380V ±10% 50Hz 3Phase
Control system

Remote control 8m cable

Color

Customized

Warranty

 1 Year
FAQ:
Q1: What is the Brand Name of this product? A1: The Brand Name of this product is Weldsuccess.
Q2: Where is the Place of Origin of this product? A2: The Place of Origin of this product is China.
Q3: What is the Certification of this product? A3: The Certification of this product is ISO/CE/CO.
Q4: What is the Minimum Order Quantity of this product? A4: The Minimum Order Quantity of this product is 1 set.
Q5: How long is the Delivery Time of this product? A5: The Delivery Time of this product is 20 working days after received your payment.
